Canon EOS C80 6K Full-Frame Cinema Camera (Canon RF)

The all new Canon EOS C80 camera is designed for limitless creative vision. The compact, full-featured camera body includes Canon's 6K full frame Back-Illuminated Stacked CMOS sensor, Cinema RAW Light and 4K/120p internal recording, Canon’s next-generation Dual Pixel CMOS AF II and a 12G-SDI interface. The EOS C80 seamlessly integrates into almost any production providing the ultimate flexibility and outstanding image quality.

Ideal for fast-paced capture and solo operators, this digital camera features triple ISO bases of 800, 3200, and 12,800 in log/raw, upgraded Dual Pixel CMOS AF II autofocus, and simultaneous 12G-SDI and HDMI video output. The EOS C80 features a 6K back-illuminated stacked full-frame CMOS sensor. The sensor offers exceptional low noise, enabling the camera to excel in a wide variety of lighting situations and maximizing the camera’s full dynamic range. The new sensor delivers faster read-out speeds than previous EOS sensors and when compared to a front-illuminated CMOS sensor, the new sensor’s architecture provides improved sensitivity as it increases light capturing efficiency and improves 4K image quality with 6K oversampling


Main Features:

• 6K FF Back-Illuminated CMOS Sensor
• 6K30, DCI 4K/2K, UHD 4K120 S35 Recording
• Full Frame and Super35 Modes
• 12G-SDI and HDMI Simultaneous Output
• Triple-Base ISO: 800, 3200, 12,800
• Cinema Raw Light LT, HEVC, AVC Codecs
• 16+ Stops of Total Dynamic Range
• Dual-Pixel CMOS AF II, Built-In NDs
• 1 x BNC Timecode, 2 x Mini-XLR Audio In
• 2 x SD Card Slots, LUT/Long GOP Support
• Recording Modes: Cinema RAW Light 12-Bit
  UHD 6K (6000 x 3164) at 23.98/24.00/25/29.97 fps [553 to 639 Mb/s]
  4368 x 2304 at 23.98/24.00/25/29.97/50/59.94 fps [293 to 678 Mb/s]
  XF-HEVC S Long GOP 4:2:2 10-Bit
  4096 x 2160 at 50/59.94/120 fps [225 Mb/s]
  3840 x 2160 at 23.98/24.00/25/29.97/120 fps [135 Mb/s]
  2048 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s]
  1920 x 1080 at 23.98/24.00/25/29.97/30.00/50/59.94/180 fps [50 Mb/s]
  XF-HEVC S Long GOP 4:2:0 10-Bit
  4096 x 2160 at 50/59.94/120 fps [150 Mb/s]
  3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s]
  2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s]
  1920 x 1080 at 23.98/24.00/25/29.97/59.94/180 fps [35 Mb/s]
  XF-HEVC S Long GOP 4:2:0 10-Bit
  2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s]
  1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s]
  XF-HEVC S Long GOP 4:2:0 8-Bit
  1280 x 720 at 23.98/24.00/25/50/59.94 fps [6 Mb/s]
  XF-AVC S Intra 4:2:2 10-Bit
  4096 x 2160 at 59.94/60.00 fps [600 Mb/s]
  3840 x 2160 at 50/60.00 fps [500 Mb/s]
  2048 x 2160 at 59.94/120 fps [300 Mb/s]
  1920 x 1080 at 50/120 fps [250 Mb/s]
  XF-AVC S Intra 4:2:2 10-Bit
  4096 x 2160 at 50/59.94/120 fps [250 Mb/s]
  3840 x 2160 at 23.98/24.00/25/29.97/120 fps [150 Mb/s]
  2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [50 Mb/s]
  1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [120 to 300 Mb/s]
  XF-AVC S Long GOP 4:2:0 8-Bit
  4096 x 2160 at 50/59.94/120 fps [150 Mb/s]
  3840 x 2160 at 23.98/24.00/25/29.97/120 fps [100 Mb/s]
  2048 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s]
  1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/180 fps [35 Mb/s]
  XF-HEVC S Intra 4:2:0 8-Bit
  2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps [9 to 16 Mb/s]
  1920 x 1080 at 23.98/24.00/25/29.97/50/59.94/60.00 fps [9 to 16 Mb/s]
  1280 x 720 at 23.98/24.00/25/29.97/50/59.94 fps [6 Mb/s]
• Unit Dimensions: 6.3 x 5.4 x 4.6" / 160 x 138 x 116 mm
  10.9 x 6.8 x 6.3" / 276 x 173 x 160 mm (With Handle, Included Battery, Mic Holder)
• Unit Weight: 2.87lb / 1.30kg (Body Only)
  3.406lb / 1.545kg (With Battery, Handle)
